| d |
20
mm
|
Inner diameter |
|---|---|---|
| D |
70
mm
|
Outer diameter |
| B |
12
mm
|
Thickness |
| r1(min) |
0.3
|
|
| r2(min) |
0.3
|
|
| Roller pitch diameter |
41.5=RU42
|
dp |
| Lubrication hole |
3.1
|
d1 |
| Rated dynamic load |
7.6
|
Cr |
| Rated static load |
8.37
|
KN |
| Installation hole relationship size(mm) |
28
|
PCD1 |
| Built in installation hole |
6-M3 through-hole, evenly configured
|
|
| PCD2 |
57
|
|
| External mounting hole |
6- φ 3.4 through-hole, evenly configured with a deep hole depth of 3.3 and a diameter of 6.5
|
|
| Installation dimensions（mm） |
36.5
|
ds |
| Installation dimensions（mm） |
48.5
|
Dh |
| Weight |
0.31
kg
|
