Single row deep groove ball bearings are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types.
Bore diameter | 1 000 mm |
Outside diameter | 1 220 mm |
Width | 100 mm |
Basic dynamic load rating | 637 kN |
Basic static load rating | 1 800 kN |
Reference speed | 750 r/min |
Limiting speed | 600 r/min |
Filling slots | Without |
Number of rows | 1 |
Locating feature, bearing outer ring | None |
Bore type | Cylindrical |
Cage | Machined metal |
Matched arrangement | No |
Radial internal clearance | CN |
Material, bearing | Bearing steel |
Coating | Without |
Sealing | Without |
Lubricant | None |
Relubrication feature | Without |
Candidate for remanufacturing | Yes |
Product net weight | 245 kg |
eClass code | 23-05-08-01 |
UNSPSC code | 31171504 |
